Fixiing Process Vacuum Brazing Machine 600kg Capacity with Manual/Automatic Operating Mode and High Capacity

Product Description:

The Tungsten Carbide Vacuum Brazing Machine is a state-of-the-art Vacuum Brazing Device designed to deliver exceptional performance and reliability for industrial brazing applications. Engineered with precision and advanced technology, this machine is ideal for achieving high-quality brazing results, especially when working with tungsten carbide materials that require meticulous control over temperature and vacuum conditions.

At the heart of this Vacuum Brazing Device is a robust chamber constructed from a quartz glass tube. The use of quartz glass ensures excellent thermal resistance and visibility, allowing operators to monitor the brazing process closely. The chamber’s dimensions of 1600*950*900 mm provide ample space to accommodate various workpieces, enabling the brazing of multiple components simultaneously. This size strikes a perfect balance between capacity and efficiency, making it suitable for both small-scale and larger production runs.

One of the standout features of this Tungsten Carbide Vacuum Brazing Machine is its impressive maximum vacuum rate of 10^-2 Pa. Achieving such a high vacuum level is critical in minimizing oxidation and contamination during the brazing process, which directly influences the strength and durability of the brazed joints. The vacuum environment also ensures that the brazing filler metals flow uniformly, resulting in consistent and reliable bonding of tungsten carbide parts.

In terms of productivity, this Vacuum Brazing Device boasts a brazing ability of up to 500 pieces per operation cycle. This high throughput capability makes it an excellent choice for manufacturers looking to optimize production efficiency without compromising on quality. Whether used in the tooling, automotive, aerospace, or electronics industries, the machine’s capacity to handle a large volume of tungsten carbide components enhances overall operational effectiveness and reduces downtime.

The heating source of the Tungsten Carbide Vacuum Brazing Machine is comprised of 18 high-performance halogen tubes. These tubes provide rapid and uniform heating, ensuring precise temperature control throughout the brazing process. The halogen heating system is not only energy-efficient but also offers excellent temperature stability, which is essential for the delicate brazing of tungsten carbide materials. The even heat distribution prevents thermal shocks and distortion, preserving the integrity of the workpieces.

Moreover, the Vacuum Brazing Device is designed with user convenience and safety in mind. The quartz glass chamber allows for clear visibility, while the advanced vacuum system guarantees a clean, contaminant-free environment. The machine’s controls are intuitive, enabling operators to set and monitor parameters such as temperature, vacuum level, and cycle time with ease. This level of control ensures repeatable and high-quality brazing outcomes.

In summary, the Tungsten Carbide Vacuum Brazing Machine is an indispensable tool for industries requiring precision brazing under vacuum conditions. Its quartz glass tube chamber, substantial size of 1600*950*900, maximum vacuum rate of 10^-2 Pa, and the capacity to braze up to 500 pieces per cycle make it a highly efficient and reliable Vacuum Brazing Device. Coupled with the powerful heating source of 18 halogen tubes, this machine guarantees excellent brazing quality, energy efficiency, and production scalability. Investing in this advanced brazing equipment will significantly enhance manufacturing processes involving tungsten carbide materials, ensuring superior joint strength, durability, and overall product performance.

Technical Parameters:

Applications:

The CTSTC Vacuum Brazing Machine, model ZT-ZKHJ180, is an advanced vacuum welding machine designed to meet the stringent requirements of modern manufacturing industries. Originating from China and certified with CE, this high-performance equipment ensures precision and reliability in vacuum soldering processes. With a vacuum level of ≤5Pa and a robust weight of 600kg, it provides a stable and controlled environment essential for high-quality brazing operations.

This vacuum soldering equipment is ideal for scenarios requiring the joining of delicate and high-value materials, such as in the production of PCD/PCBN tools. The CTSTC ZT-ZKHJ180 model supports a brazing capability of approximately 600 CNGA1204 inserts per cycle, making it highly efficient for batch processing in tool manufacturing industries. Its vacuum process encompasses cleaning, fixing, drying, and brazing, ensuring thorough preparation and flawless bonding of components.

The compact size of 1600*950*900 mm allows easy integration into existing production lines, while the packaging in a sturdy plywood box guarantees safe delivery. With a delivery timeframe of 45-60 days and flexible payment terms such as TT, LC, and Western Union, the purchasing process is streamlined for global clients. This vacuum welding machine is especially suitable for industrial applications in aerospace, automotive, electronics, and cutting tool manufacturing where precision brazing is critical.

Its versatility makes it an indispensable tool in scenarios where vacuum soldering equipment is required to produce high-quality, durable joints that withstand extreme conditions. The CTSTC Vacuum Brazing Machine is perfect for workshops and factories aiming to enhance product quality and process efficiency through state-of-the-art vacuum brazing technology. Whether for small-scale custom jobs or large-scale production runs, the ZT-ZKHJ180 model delivers consistent results with minimal maintenance.

In summary, the CTSTC Vacuum Brazing Machine ZT-ZKHJ180 is a reliable, CE-certified solution from China, offering negotiable pricing and a minimum order quantity of just one unit. Its comprehensive vacuum brazing process and high capacity make it the ideal choice for manufacturers seeking advanced vacuum welding machines and PCD/PCBN tools vacuum brazing machines to improve their production capabilities and product performance.

Customization:

CTSTC offers customized Vacuum Brazing System for Ultra Hard Materials designed to meet your specific production needs. Our Vacuum Brazing Machine, model ZT-ZKHJ180, is manufactured in CHINA and holds CE certification, ensuring high quality and safety standards.

This Vacuum Brazing Device features a spacious chamber size of 500mm x 500mm x 500mm and operates at a vacuum level of ≤5Pa, facilitated by a reliable Rotary Vane Pump. With compact dimensions of 1600*950*900 and a weight of 600kg, it is designed for efficient and precise brazing applications.

We accept a minimum order quantity of 1 unit, with pricing negotiable to suit your budget. The product is securely packaged in a plywood box for safe delivery. Delivery time ranges from 45 to 60 days, and payment terms include TT, LC, and Western Union options for your convenience.

Choose CTSTC’s Vacuum Brazing Machine for an advanced Vacuum Brazing System for Ultra Hard Materials that combines performance, reliability, and customizable service to fit your unique manufacturing requirements.
