Advanced 20KW Power Supply Vacuum Brazing Device With Quartz Glass Tube Chamber

Place of Origin CHINA
Brand Name CTSTC
Certification CE
Model Number ZT-ZHKJ180
Minimum Order Quantity 1
Price Negotiable
Packaging Details plywood box
Delivery Time 45-60 days
Payment Terms TT/LC/Western Union

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Power Supply 380V-3Phases-5Wires/20KW Weight 600kg
Max Vacuum Rate 10^-2 Pa Guarranty 1 Year
Chamber Quartz Glass Tube Brazing Capability CNGA1204 Appr. 600pcs/cycle
Operation Mode Automatic Vacuum Process 1.Cleaning,2. Fixiing Flux,3.Drying At The Temperature Of 200℃ For 30mins,4.Brazing
High Light

20KW Vacuum Brazing Device


Quartz Glass Tube Brazing Device


Quartz Glass Tube Chamber Brazing Machine

Leave a Message
Product Description

Product Description:

Our Vacuum Brazing Machine is equipped with a chamber size of 180*500mm, which can accommodate a large number of tools in a single cycle. With a weight of 600kg, it is sturdy and durable, ensuring that it can withstand the demands of continuous operation.

The brazing capability of our Vacuum Brazing Machine is impressive, with the capacity to braze approximately 600 pieces of CNGA1204 tools in a single cycle. This makes it ideal for high-volume industries that require large quantities of brazed tools to meet production demands.

Our Vacuum Brazing Machine operates in automatic mode, making it easy to use and operate. The automatic system ensures that the brazing process is carried out with precision and accuracy, eliminating the need for manual intervention and reducing the risk of errors.

The heating source of our Vacuum Brazing Machine is powered by 18 Halogen Tubes, which provide precise heating and temperature control. The Halogen Tubes ensure that the brazing process is carried out at a consistent temperature, ensuring that the brazed tools are of the highest quality.

In summary, our Vacuum Brazing System for Ultra hard Materials is a reliable and efficient solution for brazing PCD/PCBN tools. With its large chamber size, impressive brazing capability, automatic operation mode, and precise heating source powered by Halogen Tubes, it is the perfect addition to any industrial setting that requires high-quality brazed tools.

Advanced 20KW Power Supply Vacuum Brazing Device With Quartz Glass Tube Chamber 0

Technical Parameters:

Application: PCD/PCBN Inserts Brazing
Max Vacuum Rate: 10^-2 Pa
Power Supply: 380V-3Phases-5Wires/20KW
Brazing Capability: CNGA1204 Appr. 600pcs/cycle
Weight: 600kg
Heating Source: 18pcs Halogen Tubes
Chilling: Water Cooling
Max Temperature: 950°
Chamber Size: 180*500mm
Operation Mode: Automatic
Advanced 20KW Power Supply Vacuum Brazing Device With Quartz Glass Tube Chamber 1


The Vacuum Brazing Machine is best suited for brazing Tungsten Carbide, ceramics, and other ultra hard materials. It can be used in a variety of applications such as diamond tool manufacturing, cutting tool manufacturing, and drilling tool manufacturing. It is also suitable for brazing other materials such as stainless steel, copper alloys, and aluminum.

The dimensions of the Vacuum Brazing Machine are L1600×W950×H900mm and the chamber size is 180*500mm. The machine has a maximum vacuum rate of 10^-2 Pa and uses 18 pcs halogen tubes as the heating source. The Vacuum Brazing Machine is designed for automatic operation, which makes it easy to use and reduces the need for manual labor.

The Vacuum Brazing Machine is packed in a plywood box for safe transportation. The delivery time for the machine is between 45-60 days. The minimum order quantity is 1, and the price is negotiable. Payment terms include TT, LC, and Western Union.

The Vacuum Brazing Machine is the perfect solution for businesses looking to improve their brazing processes. Its high-performance capabilities, automatic operation, and ability to braze ultra hard materials make it a valuable asset in the manufacturing industry.

Advanced 20KW Power Supply Vacuum Brazing Device With Quartz Glass Tube Chamber 2

Support and Services:

The Vacuum Brazing Machine is a high-precision equipment that requires proper maintenance and technical support to ensure its optimal performance and longevity. Our product technical support and services include:

  • Installation and commissioning of the machine
  • Training for operators and maintenance personnel
  • Regular maintenance and calibration checks
  • 24/7 technical support and troubleshooting
  • Replacement of parts and components
  • Upgrades and retrofits to improve performance and efficiency
  • Consulting services for process optimization and customization

Our team of experienced professionals is dedicated to providing exceptional support and service to our customers. Contact us for more information on our product technical support and services.


Packing and Shipping:

Product Packaging:

The Vacuum Brazing Machine product will be packaged in a sturdy cardboard box with sufficient protective materials to prevent any damage during transit.


We offer free shipping for the Vacuum Brazing Machine product to most locations within the United States. For international orders, shipping charges will apply and will vary depending on the destination country. All orders will be shipped within 3-5 business days after payment confirmation, and delivery times will depend on the shipping method selected at checkout.
