CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools

Place of Origin CHINA
Brand Name CHN-TOP
Certification CE
Model Number ZT-ZKHJ180
Minimum Order Quantity 1 SETS
Price Negotiable
Packaging Details WOODEN CASE
Delivery Time 5-60 WORKING DAYS
Payment Terms L/C, T/T, D/A, MoneyGram
Supply Ability 50 SETS/MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model No. ZT-ZKHJ180 Brand CHN-TOP
Product Name Vacuum Brazing Machine Application PCD PCBN DIAMOND TOOLS BRAZING
Vacuum Process Clean, Fixiing, Drying And Brazing
High Light

CE Vacuum Brazing Machine

,

PCD Vacuum Brazing Machine

,

PCD automatic brazing machine

You can tick the products you need and communicate with us in the message board.
Dimensions 1600*950*900mm( L*W*H)
Power supply 3 phases-380V-15KW
Chamber Quartz Glass Tube
Chamber size ¢180*500(L)*T4(mm)
Brazing Capability For example: CNGA1204 approx 350pcs/cycle
Max Temperature 950℃
Limited vacuum rate 10-6 Torr (10-4 Pa)
Vacuum Rate 10-5 Torr (10-3 Pa)
Heating source 18 pcs halogen tubes
Chilling Water
Leave a Message
Dimensions 1600*950*900mm( L*W*H)
Product Description

PCD BLANK TOOLS EQUIPMENT TOOLS MACHINIING PCD BLANK PCD TOOLS VACUUM BRAZING MACHINE

Vacuum Brazing machine is excellent for brazing ultra-hard material(PCD /PCBN/ MD/ ND /CVD), TUNGSTEN carbide, ceramics and others;

It's fully automatic and very easy to operate at high efficienty

  • Materials: Natural Diamond, Monocrystal diamond, PCD , PCBN, CVD and cermet
  • Substrate material:CERMET, tungsten carbide, steel, stainless steel, steel alloy ,ceramic, etc



CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools 0

MAIN FEATURES
1, PLC control, SCR heating, touch panel,
automatic implement after simple setting with easy temperature control.
2, No oxidation, clean surface, environment-friendly.
3, Brazing quantity is more than 500pcs (for CNGA1204), reduce total cost.
4, The machine is fully automatic and once loaded, the cycle time is approximately 70-120 mins.
5, Reduction of distortion even very small tool insert can be brazed.
6, High brazing strength, 2 times higher than induction welding.
7, Advanced artificial quartz stone for table-board, elegant, high temperature resistance.
Besides the standard machine, we can offer OEM according to clients’ requirement.
Technical Parameters:
Dimensions 1600*950*900mm( L*W*H)
Power supply 3 phases-380V-15KW
Chamber Quartz Glass Tube
Chamber size ¢180*500(L)*T4(mm)

Brazing Capability

For example: CNGA1204 approx 350pcs/cycle

Max Temperature 950℃
Limiting Vacuum rate 10-6 Torr (10-4 Pa)
Vacuum Rate 10-5 Torr (10-3 Pa)
Heating source 18 pcs halogen tubes
Chilling Water

CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools 1
CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools 2

CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools 3

CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools 4

Brazing Samples

CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools 5

CE Certification Vacuum Brazing Machine Automatic For PCD Blank Tools 6



CHN-TOP is the company offer comprehensive solutions for diamond tools making

Machines: PCD/PCBN diamond grinding machine, Vacuum brazing machine, laser cutting machine,
chip breaker machines, laser engraving machine and polishing machines
Material: World famous PCD/ PCBN blanks , such as ILJIN, Element six, Hypersion, Adico, CHN-TOP
CTSTC, SF with competive price
Machining service: Cutting for segements, brazing service for MD/PDC cutter, PCBN tools,
Notching service for tools, chip breaker machining service and grinding service
