Adjustable Grinding Pressure PCD Grinding Machine for Grinding 210*160mm Cross Table 150*40*40mm Grinding Wheel Size

Product Description:

The PCD Grinding Machine is a high-precision equipment designed specifically for grinding PCD/PCBN materials. With advanced features and precise specifications, this machine is ideal for sharpening PCD/PCBN tools with utmost accuracy and efficiency.

Key Features:

• Grinding Wheel Oscillation Frequency: 0-45/min (adjustable) - The machine offers a versatile range of oscillation frequency settings to suit various grinding requirements and achieve optimal results.
• Cross Table Swiveling Angle: 270° - The cross table of the grinder can swivel up to 270 degrees, providing flexibility in positioning the workpiece for precise grinding.
• Readout of Linear Gratings: 0.001mm - The equipment is equipped with a high-precision linear gratings readout system that ensures accurate measurement and control during the grinding process.
• Dimension: 1200*1168*1530mm (L*H*W) - The compact and ergonomic design of the machine makes it space-efficient while offering ample working area for grinding operations.
• Image System Resolution: 1280dpi*960dpi - The high-resolution image system allows for detailed visualization and inspection of the grinding process, ensuring quality and precision.

Whether you are working with PCD/PCBN materials or tools, this grinder is a reliable and efficient solution for achieving superior grinding results. Its adjustable grinding wheel oscillation frequency, wide swiveling angle of the cross table, precise readout of linear gratings, compact dimensions, and high-resolution image system make it a versatile and powerful tool for various grinding applications.

Technical Parameters:

Applications:

The PCD Grinding Machine by CTSTC is a versatile and high-precision tool designed for grinding PCD (polycrystalline diamond) and PCBN (polycrystalline cubic boron nitride) materials with ease. This innovative machine is a must-have for industries that work with hard materials such as tungsten carbide, ceramics, and composites.

With its advanced features and specifications, the PCD Grinding Machine is ideal for a variety of application occasions and scenarios:

1. Tool Manufacturing Industry: The PCD grinder is perfect for sharpening and regrinding PCD and PCBN cutting tools used in the tool manufacturing industry. Its precise readout of linear gratings at 0.001mm ensures accurate and consistent grinding results.

2. Automotive Industry: In the automotive industry, where precision is key, the PCD grinding machine excels in grinding hard materials used in engine components, brake systems, and transmission parts. The machine's optical tube distance of 300mm allows for easy maneuvering and grinding of intricate parts.

3. Aerospace Industry: With its tip radius ranging from 0-70mm, the PCD Grinding Machine is well-suited for grinding aerospace components made from PCD and other hard materials. The machine's spindle power of 2.2kw ensures efficient material removal and surface finishing.

4. Precision Machining Workshops: Whether it's for prototyping or mass production, the PCD Grinding Machine is a valuable asset in precision machining workshops. Its ability to grind hard materials with high precision makes it a go-to machine for achieving tight tolerances and superior surface finishes.

CTSTC's PCD/PCBN Grinding Machine, proudly made in CHINA, comes with a CE certification, guaranteeing its quality and safety standards. Customers can order a minimum quantity of 1 machine, with packaging details in a sturdy plywood box to ensure safe delivery. The delivery time for the machine is between 45-60 days, and payment terms accepted include TT, LC, and Western Union.

Customization:

Product Customization Services for the PCD Grinding Machine:

Brand Name: CTSTC

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1

Packaging Details: plywood box

Delivery Time: 45-60 days

Payment Terms: TT/LC/Western Union

Net Weight: 1450kgs

Grinding Wheel Traveling Range: 170mm

Grinding Wheel Oscillation Distance: 0-40mm (adjustable)

Spindle Power: 2.2kw

Tip Radius: 0-70mm
