2.2KW PCD Grinding Machine
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Brand | CHN-TOP | Machine Body | Over 5 Years Natural Age Cast Iron |
|---|---|---|---|
| Application | PCD Tools PCBN Tools, Carbide Tools | Type | Manual Similar |
| Grinding Wheel Oscilation Frequency | 0-45/min Adjustable | Grinding Wheel Oscillation Distance | 0-40mm Adjustable |
| Grinding Wheel Height Adjustment | 140mm | Grinding Wheel Traveling Range | 170mm |
| Grinding Wheel Inclination | -13 +24 | Cross Table Swiveling Angle | 270 |
| Worktable Size | 210*160mm With 4 T Grooves | Readout Of Linear Grating | 0.001mm |
| Spindle Power | 2.2KW | ||
| High Light | 140mm PCD Grinding Machine,2.2KW PCD Grinding Machine,450N PCD Grinding Machine |
||
You can tick the products you need and communicate with us in the message board.
| Radius Tip | 0-70mm | |
|---|---|---|
| Grinding pressure | 0-450N Adjustable | |
| Spindle speed | 0-4200RPM adjustable | |
| Grinding wheel size | 150*40*40mm (D*H*T) | |
| Grinding wheel oscillation frequency | 0-45/min adjustable | |
| Grinding wheel oscillation distance | 0-70mm adjustable | |
| Grinding wheel height adjustment | 140mm | |
| Grinding wheel stroke range | 400mm | |
| Grinding wheel inclination | -13°-+24° | |
| Cross table swiveling angle | 0-270° | |
| Size of cross table | 210*160mm with 4 T slots | |
| Workable infeed hand wheel division | 0.001mm/ 1 division | |
| Spindle Power | 2.2KW | |
| Dimension | 1850*2200*1650mm( L*H*W) | |
| Net weight | 2000kgs |
Product Description
PCD PCBN tools equipments ZT-90 manual pcd grinding machine
ZT-90 is a maual grinder which is similar specification with FARM 200D.There is XYZ axis, and X axis can be angle adjusting, a hand wheel to help do small adjust. The grinding head can be up and down.
Online CCD monitor and HD camera can help you get high clear image
Features
1), Extremely rigid construction with heavy duty cast iron body, more than 18 months natural ageing, stable and durable;
2), Swing mechanism utilizing ball-screw by a servo motor, smoother, more stable and durable.
3), The frequency converter is JAPAN FUJI brand;
4), The whole pneumatic system use Japan SMC products, and is designed and selected by domestic top pneumatic system engineers to realize rapid advance and retreat and flexible grinding of the worktable;
5), CCD camera with LCD monitor and precision scale for easy setting up and inspection in grinding;
6), Monitor scope with zoom system for adjustable from 7-45 magnification even 0.05 radius can grinded and inspected.
TECHNICAL PARAMETERS
|
Model |
ZT-90 |
|---|---|
| Tip Radius | 0-70mm |
| Grinding Pressure | 0-450N adjustable |
| Spindle Speed | 0-4200RPM adjustable |
| Grinding wheel size | 150*40*40mm (D*H*T) |
| Grinding wheel oscillation frequency | 0-45/min adjustable |
| Grinding wheel oscillation distance |
0-70mm adjustable |
| Grinding wheel height adjustment | 140mm |
| Grinding wheel stroke range | 400mm |
| Grinding wheel inclination | -13°-+24° |
| Cross table swiveling angle | 0-270° |
| Size of cross table | 210*160mm with 4 T slots |
| Workable infeed hand wheel division | 0.001mm/ 1 division |
| Spindle Power | 2.2KW |
| Dimension | 1850*2200*1650mm( L*H*W) |
Grinding Samples
Factory View
Q: Are you trading company or manufacturer ?
A: We are manufactory for PCD,CBN diamond tools equipments and service, we have our own R&D team and production workshop. We can develop our customers' unique products according to their needs.
Q: How long is your delivery time?
A: Generally it is 2-3 days for CNC diamonds tools machining, and 45-60 days for machines.
Q: How about your after-sales system?
A: We have a comprehensive after-sales system, which can provide one-on-one online video service according to the needs of customers, and one-on-one service to solve customers' worries.
Q: How about your delivery date for PCD/PCBN blank?
A: 1), PCD/PCBN Blank, we have signed a Chinese agency agreement with international big brands, customers do not need to worry about genuine and delivery problems;
2), We can provide a wide range of products with PCD/ PCBN Blank, customers can choose goods according to different needs, we also have self-developed domestic PCD with high quality, the price is very competitive.
Q: How about the cutting thickness and width of Laser cutting machine?
A: 1), Cutting thickness, single-sided cutting maximum thickness of 4-5mm, double-sided cutting maximum thickness of 8 10mm.
2), Slit width: 0.05-0.15mm, accuracy can reach 0.01mm.
Recommended Products
