Industrial CNC Fiber Laser Cutting Machine For PCD / PCBN Tools Engraving
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | PCD/PCBN Cutter | Model | 2022 New |
|---|---|---|---|
| Certificate | CE, FDA | Product Name | Laser Engraving Cutting Machine For PCD / PCBN Tools Cutting |
| Laser Source | Fiber | Dimension | 1500*920*1640mm |
| Power | 380V | After-sales Service | 2 Years |
| High Light | 2000Hz CNC Fiber Laser Cutting Machine,22 Degree CNC Fiber Laser Cutting Machine,PCBN Tools CNC Fiber Laser Cutter |
||
Product Description
Laser Engraving Cutting Machine For PCD / PCBN Tools Cutting
The fiber laser of ZT-JG6S machine adopts the maintenance-free type, which saves the regular cleaning of the resonator and the calibration and maintenance of the optical path in the daily use, the fiber laser cutting machine is more environmentally friendly and simple and convenient.
Mainly suitable for cutting ultra-hard materials ( PCD, PCBN, Cemented Carbide, Ceramics). It can also cut some materials that can not be machined by wire cutting. The cutting surface is fine, with high cutting speed, precision and working efficiency. It is more superior than normal YAG pump laser cutting machine by 2 times.
Technical Parameters:
|
Power supply requirements |
380V50Hz, Five-core four-square power cord |
|
Working environment |
Room temperature 20~40℃, humidity ≦60%, away from oil source |
|
Cooling Mode of Machine |
Adopt dual temperature cooling system , laser cutting head cooled by room temperature water. Laser cooled by 22℃cooling circulating water, and for manufacturing workpiece cooled by purify oil-free compressed air. |
|
Laser Source |
Fiber laser |
|
Duty Ratio |
1~100% |
|
Frequency |
1-2000 Hz |
|
Power percentage |
1%~100% |
|
Four Axis stroke |
300*300*50mm A-Axis 0±30° |
|
Maximun power output |
3000W |
|
Positioning accuracy |
≦± 0.005mm |
|
Repeat positioning accuracy |
≦± 0.005mm |
Daily maintenance and maintenance
1. Check the operation of the laser carefully before turn on daily, check the equipment button indicator lamp, stop the ammonium button key switch is not normal.
2. check the circulating water level of water cooler water tank, if not added in time.
3. Check protective lens for damage before daily cutting.
4. Clean up the dust and debris inside the worktable after each shift is completed.
5. After one year of using , the machine tool and worktable should be adjusted regularly to ensure the cutting accuracy of the machine tool.
If the equipment is not in use for a long time, please apply butter to the moving parts and rust-prone parts of the machine tool to prevent rust.
