CCD Visual Positioning PDC Laser Engraving Machine

Place of Origin CHINA
Brand Name CTSTC
Certification CE
Model Number ZT-JGDK200
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details 1280*950*1900mm
Delivery Time 45-60 days after prepayment
Payment Terms T/T, D/P, D/A, L/C
Supply Ability 20 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Automatic Laser Engraving Machine Condition New
Certification CE, FDA Warranty 2 Years
Laser Source Fiber Laser Application Ultra Hard Material Engraving
After-sales Service Provided Engineers Available To Service Machinery Overseas CNC Or Not Yes
High Light

PDC Laser Engraving Machine

,

CCD Visual Positioning Laser Engraving Machine

,

PDC Laser Engraver

Leave a Message
Product Description



ZT-JGDK200 PDC Automatic Laser Engraving Machine



ZT-JGDK200 laser engraving machine is mainly used for special-shaped diamond surface processing of PDC of petroleum drill head, it can engrave PDC with complex 3D graphics. The machine adopts visual recognition for automatic positioning, the industrial camera is imported from Germany, automatic focusing, closed-loop control for all motions.



CCD Visual Positioning PDC Laser Engraving Machine 0





Design Features:

• CCD visual positioning, automatic focusing, the processing shapes can be arbitrary 3D graphics, and the processing status can be viewed.

• Standard 3D software input, combined parameter adjustment, rough and finish machining can be completed by one key.

• Closed-loop high precision work table control system is more precise for positioning.

• Positioning accuracy ≤0.01mm, machining precision ≤0.05mm.

• Multiple work pieces loading, 64 pcs per cycle, one key operation, unattended operation.

• High processing efficiency, removes 0.005mm per layer, the maximum machining depth is 30mm, surface roughness ≤1.2um.



CCD Visual Positioning PDC Laser Engraving Machine 1CCD Visual Positioning PDC Laser Engraving Machine 2
