PCD Inserts CNC Fiber Laser Cutting Machine
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Laser Cutting | Applicable Material | Metal, Crystal, PCD/PCBN |
|---|---|---|---|
| Graphic Format Supported | AI, PLT, DXF, BMP, Dst, Dwg | Cutting Speed | 600mm/min |
| After-sale Service | Video Technical Support, Online Support, | Core Components | Motor, PLC |
| Condition | New | ||
| Highlight | 600mm/min CNC Fiber Laser Cutting Machine,PCD Inserts CNC Fiber Laser Cutting Machine,PCD Inserts CNC Fiber Laser |
||
Product Description
PCD Blank Inserts Laser Cutting Machine CHNTOP Multiaxis XYZ And A
Quick Details
1 High speed, high precision, high efficiency and low cost
2 Users-friendly operating interface
3. Cutting database help users choose optimal cutting parameter
4 Fast pallet exchanger and full enclosure
Description:
The machine bed with high rigidity and high wear resistance ,adopts high-temperature annealing process to ensure that the bed will not be deformed for a long time;
Adopt precision gear rack transmission mode to ensure highly dynamic performance;
Specifications:
| Technology Parameters | |
| Laser Source | Fiber |
| Control system | X/Y/Z high precision worktable with rotary A axis |
| Software system | Based on Windows R&D control system |
| Monitor system | CCD same axis monitor |
| Laser head | Special laser head |
| Focus system | High resolution laser sensor |
| Body | Marble Body base |
| Electric Power | 380v-3phase-5wires 50HZ |
| Power | 6KW |
| Laser Power | 3000W |
| Worktable | 220*220*100mm(x*y*z) |
| A Axis rotation angle | ±30°(can cut relief angle) |
| Repeating Position Accuracy | ≦0.005mm(stepping system) |
| ≦0.003mm(servo system) | |
| Load | ≦15KG |
| Max speed | 600mm/min |
| Kerf Width | ≦0.10mm |
Applications:
This machine is mainly suitable for cutting ultra-hard materials(PCD/ PCBN/ hard alloy),also applicable to materials that cannot be processed by wire cutting.
