GRINDING MACHINE FOR PCD/PCBN

Other Videos
April 22, 2022
Category Connection: PCD Grinding Machine
Chat Now Contact Us
Tags:
#4200RPM PCD Grinding Machine #PCD automatic grinder machine #450N cnc internal grinding machine
Brief: Discover the Automatic PCD/PCBN Grinder Machine, an economical and fully automated solution for grinding hard materials like PCD and PCBN. With adjustable tip radius up to 70mm and advanced CNC technology, this machine ensures precision and efficiency in toolmaking.
Related Product Features:
  • Adjustable tip radius from 0-70mm for versatile grinding applications.
  • Grinding pressure adjustable up to 450N for precise material removal.
  • Spindle speed ranges from 0-4200RPM, ensuring optimal performance.
  • Equipped with a 150*40*40mm grinding wheel for durable and efficient grinding.
  • 5-axis CNC with 2-axis linkage for fully automatic grinding processes.
  • Latest vision technology enables on-line detection and automatic grinding.
  • Heavy-duty cast iron body ensures stability and durability.
  • Pneumatic system by Japan SMC brand for rapid feed and flexible grinding.
Faqs:
  • What materials can the Automatic PCD/PCBN Grinder Machine handle?
    This machine is designed for grinding hard and ultra-hard materials, including PCD, PCBN, and hard alloys.
  • Is the grinding process fully automated?
    Yes, the machine features 5-axis CNC with 2-axis linkage, enabling fully automatic grinding with parameter memory and error alarms.
  • What is the maximum grinding pressure the machine can apply?
    The grinding pressure is adjustable up to 450N, allowing for precise control over material removal.
